DC-DC Step Up Down Module 5-32V to 1.2-35V XL6009/XL6019 Adjustable Module QS-1212CBDE-20W with Enclosure

https://www.qskj.cc/web/image/product.template/8471/image_1920?unique=f746b20
(0 review)

2.14 2.14 USD 2.14

¥ 15.00

Not Available For Sale


    This combination does not exist.


    Share :
    100% original guarantee
    Return within 30days
    Free delivery on all orders

    Brand: QSKJ

    Model: QS-1212CBDE-20W with Enclosure

    Features:

    • New original XLSEMI chip, to prevent counterfeiting, disassemble chip
    • Imported chip electrolytic capacitors, not peer-made domestic capacitors.
    • Up to 400Khz operating frequency, and LC filter circuit, the output ripple is very low.
    • Imported TDK inductance, the heat and interference to a minimum.
    • Input and output of three MLCC multilayer ceramic capacitors, anti-jamming to enhance stability.
    • PCB using the A-class board material, to prevent cardboard, garbage board.
    • Built-in MOSFET, with the LM2577 built-in transistor say goodbye, can reach 94% of the high efficiency.
    • Increase the enable port, you can control the boost circuit is working.
    • QS-1212CBDE-20W power supply module with enable port
    • (Please click here for heat sink connection
    • Size: 49 (L) * 23.4 (W) * 11.4 (H) mm (without potentiometer)
    • The following parameters are still in the adjustment, the specific parameters, please consult
    • According to customer requirements, QSKJ also introduced XL6009 program, high cost. QSKJ produced ~ to create quality.

    Parameters:

    • Modular nature: non-isolated step-up and down module
    • Input voltage: 5-32VOutput current: 1.5A (MAX)
    • Input current: 4A (MAX)
    • Output power: natural cooling 20W, plus heat sink 25W (MAX) the actual power
    • Maximum output power = input voltage * 4A * conversion efficiency
    • Conversion efficiency: Measured common voltage and current efficiency (below for reference only)
    • Output Ripple: Input 12V Output 24 0.5A Ripple 30MV 20M Bandwidth (for reference only)
    • Operating temperature: industrial (-40 ℃ to +85 ℃) (ambient temperature exceeds 40 degrees, please reduce the power to use, or strengthen the heat)
    • Full load temperature rise: 45 ℃
    • Working frequency: 400khz
    • No-load current: typical 15mA (5V to 12V)
    • Load regulation: ± 0.5%
    • Voltage regulation: ± 0.5%
    • Dynamic response speed: 5% 200uS
    • Enable control port: Yes, high level 1.4V-VIN (ON), low level 0-0.8V (OFF), default high level
    • Short circuit protection: None (Please input fuse or protective circuit at input)
    • Input Reverse Protection: None, please tie in with our reverse protection board or in the input series diode.
    • Installation: can be screwed (fixed hole 3 mm), 2 fixed holes
    • Wiring method: welding, plus the pin can be directly welded on the PCB
    • Output voltage: continuously adjustable (1.2-35V) ; fixed output (1.2-35V between any choice), please tell the treasurer when buying;  If you need higher voltage please contact me directly.
