DC-DC Converter 13-24V to 12V 0.5A Non-isolated Step Down Module QS-7812-0.5A

Price:

16.80


1604 Character LCD Display Module with Blue Backlight Color
1604 Character LCD Display Module with Blue Backlight Color
4.31
4.31
15W 25W E14 SES LED Edison Bulb AC220V Home Light LED Filament Light Bulb
15W 25W E14 SES LED Edison Bulb AC220V Home Light LED Filament Light Bulb
3.08
3.08

DC-DC Converter 13-24V to 12V 0.5A Non-isolated Step Down Module QS-7812-0.5A

https://www.satistronics.com/web/image/product.template/6695/image_1920?unique=99581fd
(0 review)

3.78 3.7800000000000002 USD 3.78

¥ 27.00

Not Available For Sale


  • Input Voltage

This combination does not exist.


Share :
100% original guarantee
Return within 30days
Free delivery on all orders

Brand: QSKJ

Model: QS-7812-0.5A

Parameters:

  • Module Properties: Non-isolated step-down module (buck)

  • Rectifier mode: Synchronous rectification

  • Input voltage: 13-24V/13-32V

  • Output voltage: 12V (precision ± 1%)

  • Output power: 6W

  • Recommended input and output capacitors: input capacitance 10UF (ceramics), the output capacitor 22UF (ceramic)

  • Maximum capacitive load: 1000UF

  • Output current: 0.5A

  • Conversion efficiency: input voltage 6.5 V 94% (highest), input voltage 20V 85% (minimum)

  • Operating temperature: industrial - grade (-40 ° c to + 85 ° c) (85 ° c output current 0.5 A)

  • The maximum case temperature at working: 100 ° c

  • Full load temperature rise: 50 ° c

  • Load regulation: ± 0.5 %

  • Voltage regulation: ± 0.5 %

  • Output ripple: 0.5A load current (typical application circuit, the input of ceramic capacitors 10UF, output ceramic capacitors 22UF)

  • Input 14V output ripple 60mV

  • Input 24V output ripple 100mV

  • 20V input ripple output 45mV

  • Bandwidth: 20M

  • If you ripple to lower the need, please install LC filter at the output

  • Dynamic response speed: 5% 200uS

  • Short circuit protection: current limit (3A), self-recovery

  • Over-temperature protection: 150 ° c

  • Static current: 7-20 mA (the higher the input voltage, the higher of the static current)

  • Input reverse polarity protection: None

  • Wiring: Welding, the SIP-3 package, compatible with the LM7805.


Note:

  • Integrated within the filter capacitor, even without to external capacitor, the item can work properly.

  • In order to lower the output ripple, please install filter capacitor at the input and output port.
