4S 12A 14.8V 16.8V 18650 Lithium Battery Protection Board 4 Cells Li-ion Lipo Polymer Charger Protection BMS/PCM/PCB Module

https://www.satisled.com/web/image/product.template/6997/image_1920?unique=99581fd
(0 review)


JH-88586-JH-886109-3.7V

1.53 1.53 USD 1.53

¥ 11.00

Not Available For Sale


    This combination does not exist.


    Categories :
    Battery & Cases
    SKU :
    2044045
    Share :
    100% original guarantee
    Return within 30days
    Free delivery on all orders

    Parameters:

    • Model: Long HX-4S-A01

    • Short section HX-4S-A10

    • Short Size: 65 * 17 * 3.0mm

    • Overcharge voltage range: 4.25-4.35v ± 0

    • Overpressure voltage range: 2.3-3.0v ± 0.05v

    • Upper working current: 6-8A

    • Operating temperature: -40 --- +50 ℃

    • Upper limit instantaneous current: 12A

    • Storage conditions: -40-- +80 ℃

    • Quiescent current: less than 30uA

    • Effective life: more than 50,000 hours

    • Internal resistance: less than 100mΩ

    • Short circuit protection: can be protected, need to charge recovery

    • Charging voltage: 16.8V-17V

    • The protection board device description: components for the S-8254AA protection chip and AO4407 * 4.
