12A 3.2V PCB BMS Protection Board 26650 18650 LiFePO4 Battery Cell

https://www.satisled.com/web/image/product.template/6795/image_1920?unique=99581fd
(0 review)

0.83 0.8300000000000001 USD 0.83

¥ 6.00

Not Available For Sale


    This combination does not exist.


    SKU :
    1941854
    Share :
    100% original guarantee
    Return within 30days
    Free delivery on all orders

    Features:

    Over charging protection, over discharge protection, short circuit protection, over current protection function

    Parameters:

    • Overcharge detection voltage: 3.75V±0.25V

    • Overcharge release voltage: 3.6V±0.25V

    • Over discharge detection voltage: 2.1±0.05V

    • Overcurrent detection current: 15A

    • Continuous operating current: 12A

    • Charging voltage: 3.6V

    • Size: 35*7.6*2.2MM

    • MOS: 8205A*6

    Connection description:

    • B+ connect to battery+

    • B- connect to battery+

    • P+ for battery output input+

    • P- for battery output input-
